Video Link
Model :LK-SP
Power Options : 20W /30W /50W/100W
Application Materials : all metal ,such as stainless steel ,titanium ,cooper ,gold ,silver, aluminum and some Eng’g plastics PVC PE ,TUP ,ABS ....
Product Advantages : Perfect laser beam quality with stable speed for long time marking、Split portable model easy for transportation and save work space
24 Month maintenance
Fast delivery
24 Hour treatment
Production video
Feature :
1.Excellent Laser Source
Adopt optical fiber laser source , brand options :Ryacus ,Max ,JPT, IPG ,....
No optical pollution, low power coupling loss, and many unique advantages in laser marking applications
2.Lower consume& cost
Photoelectric conversion rate up to 30%, whole machine power consumes less than 500w. optical fiber laser marking machine was 1/10 consume than diode pump solid state laser marking machine ,it save energy cost
3.EZCAD Marking Software
The laser marking software runs on any Windows operation system, the vector image created by AutoCad and Coreldraw could be easily imported in DXF or PLT format, the software generates barcode, 2D code, serial number, date and time data, all windows fonts are supported.
4.Maintenance Free Operation
Laser does not require any maintenance and does not require adjustment or cleaning of the lens.
|
Laser power |
20W /30W/50W/100W |
|
Laser Type |
Fiber laser |
|
Focus mode |
Galvo head manual adjust distance / Double red light focus |
|
Effective working area |
70*70~300*300mm |
|
Marking depth |
0.01-1mm (adjustable according to material ) |
|
Line width |
0.01-0.05mm |
|
Marking Speed |
≤12000 mm/s |
|
Repeatability |
≤0.001mm |
|
Marking accuracy |
≤0.001mm |
|
Marking software |
EZCAD2 |
|
Marking content |
Image processing,Common vector images are supported. (ai, dxf, dst, plt…) Common types of images are supported. (bmp, jpg, gif, tga, png, tif…) Serial number , QR code, Bar code ....... |
|
Machine size |
650*400*610mm |
|
Package size |
750*460*810mm |
|
Machine net weight |
58KGS |
|
Machine gross weight |
66KGS |
